Top 10 ✔️ SHOP FOX 10 HP 24IN. WIDE BELT SANDER 🔔

***SPECIAL ORDER PLEASE ALLOW 6 TO 8 WEEKS FOR DELIVERY***

Numeric control pad and digital readout provide the ultimate in precision. Other features include quick-change belt system with automatic belt tensioning, air-controlled automatic belt tracking system, motorized table elevation control, adjustable air-controlled belt oscillation system, and load meter. Certified to CSA and UL standards.

Features:

Emergency stop bar with brake
Manual and motorized table elevation control
Sanding load meter
Digital readout and controls

Specifications:

Sanding motor: 10 HP, 220V, single-phase, 1725 RPM, 50A
Feed motor: 1 HP, 220V, single-phase, 1725 RPM, 7A
Elevation motor: 1/3 HP, 220V, single-phase, 1725 RPM, 3A
Drum speed: 3550 FPM
Drum diameter: 8″
Feed rate: variable, 15–49 FPM
Max. stock width: 24″
Max. stock thickness: 6″
Min. stock thickness: 1/8″
Required air pressure: 75 PSI @ 7 CFM
Sanding belt size: 25″ x 60″
Dust port: (2) 4″
Made in an ISO 9001 factory
Footprint: 39-1/4″W x 19-1/4″D
Height with dust ports: 71″
CSA certified meeting CSA C22.2 #105–1953 and UL 987–7 standards
Approximate shipping weight: 848.2 Kg (1870 lbs.)
